Product Attributes
| Categories | Industrial Automation and Controls – PLC Module |
| Manufacturer | Omron Automation and Safety |
| Series | CJ1W |
| Part Status | Active |
| Model | CJ1W-SCU31-V1 |
| Type | Serial Communication Module |
| Serial ports | 2 x RS-422A/485 |
| Current consumption | 380 mA (maximum) at 5V DC from PLC power supply |
| Protocol | Host Link, protocol macro, NT Link, or loopback test can be selected for each port. |
| CPU Rack | 10 units |
| Maximum number of I/O points | – |
| Control method | – |
| Memory Size | – |
| Control and status ares size | – |
| Mounting Type | DIN Rail |
| Termination Style | D-sub |
| Maximum Input/output | – |
| Features | – |
| Operating Temperature | 0°C……+55°C |
| Ingress Protection | IP30 |
| Software | SYSMAC, SYSWIN |
| Approvals | CE, CSA, N, UL |
| Weight | 110g |
